CW800-T

Description

Overall dimensions 1360X690X1280mm
Motor power 800W
Drive system 24V Sealed Transaxle
Battery 12V*2 75AH
Controller PG 120A
Charger  5A
Max. speed (km/h) 15km/h
Max. loading weight 135kgs
Wheel  Rear 12', Front 10'
Travel range up to 55km
Turning radius 1.1m
Max. climbing grade 15°
Ground clearance 100mm
Weight w/o battery 80kgs
Total weight w/bat. 116kgs
Packing size body:139*71*65
seat:60*52*34
